Sometimes ‘light work’ feels like anything but. There’s plenty to be done around the stables, and that fence in the yard won’t build itself. But at least there’s one thing you don’t have to worry about – your Honda Fourtrax 250 ATV. Anything but a light-weight.
| Classification | Light work ATV |
| Engine | 229cc air-cooled, wet-sump, longitudinally mounted OHV 4-stroke single cylinder |
| Carburation | Piston valve, throttle bore size 20mm |
| Ignition | CDI with electronic advance |
| Starter | Electric with auxiliary recoil |
| Transmission | Five forward gears with reverse, auto clutch with option of manual or electric shift (ESP) |
| Drive | 2wd Direct rear drive-shaft |
| Front Suspension | Independent double-wishbone 130mm (5.1”) travel |
| Rear Suspension | Swingarm with single shock, 125mm travel |
| Power Steering | No |
| Front Brakes | 130mm dual, hydraulic drums |
| Rear Brake | 140mm sealed mechanical drum |
| Front tyres | 22 x 7-11 |
| Rear tyres | 22 x 10-9 |
| Fuel Capacity (l) | 9.1L, incl. 2.6L reserve |
| Bore x Stroke (mm) | 68.5 x 62.2 |
| Dimensions – Length (mm) | 1905 |
| Dimensions – Width (mm) | 1035 |
| Dimensions – Height (mm) | 1070 |
| Wheelbase (mm) | 1131 |
| Seat Height (mm) | 793 |
| Ground Clearance (mm) | 150 |
| Towing Capacity (kg) | 225 |
| Front Rack Capacity (kg) | 15 |
| Rear Rack Capacity (kg) | 30 |
